Four Point Contact Ball Slewing Bearing (External Gear)

Features and Benefits:

An Outer Ring and Inner Ring/42CrMo or 50Mn

Outer Gear Type

Steel Balls/GrCr15 orGrCr15SiMn、Separators

NBR Seals

Tolerance and Clearance Available

Precision/P0、P2、P4、P5

Brand/LYNBC、OEM、ODM

Quality Exchangeable with RotheErde、SKF、INA、IMO、Kaydon、Silverthin Bearing

Designation	Boundary Dimension			Mounting Hole Size				Structure Size					Basic load ratings	Mass (kg)
	Boundary Dimension			Mounting Hole Size				Structure Size					Basic load ratings
	D	d	H	D₁	D₂	n	Φ mm	n₁	D₃	d₁	H₁	h	Coa(10KN)
	mm			mm		n	Φ mm	n₁	mm				Coa(10KN)
010.30.500	602	398	80	566	434	20	18	4	501	498	70	10	129	85
010.30.560	662	458	80	626	494	20	18	4	561	558	70	10	144	95
010.30.630	732	528	80	696	564	24	18	4	631	628	70	10	187	110
010.30.710	812	608	80	776	644	24	18	4	711	708	70	10	212	120
010.40.800	922	678	100	878	722	30	22	6	801	798	90	10	313	220
010.40.900	1022	778	100	978	822	30	22	6	901	898	90	10	355	240
010.40.1000	1122	878	100	1078	922	36	22	6	1001	998	90	10	394	270
010.40.1120	1242	998	100	1198	1042	36	22	6	1121	1118	90	10	443	300
010.45.1250	1390	1110	110	1337	1163	40	26	5	1252	1248	100	10	554	420
010.45.1400	1540	1260	110	1487	1313	40	26	5	1402	1398	100	10	617	480
010.45.1600	1740	1460	110	1687	1513	45	26	5	1602	1598	100	10	702	550
010.45.1800	1940	1660	110	1887	1713	45	26	5	1802	1798	100	10	793	610
010.60.2000	2178	1825	144	2110	1891	48	33	8	2202	1998	132	12	1210	1100
010.60.2240	2418	2065	144	2350	2131	48	33	8	2242	2238	132	12	1350	1250
010.60.2500	2678	2325	144	2610	2391	56	33	8	2502	2498	132	12	1500	1400
010.60.2800	2978	2625	144	2910	2691	56	33	8	2802	2798	132	12	1680	1600
010.75.3150	3376	2922	174	3286	3014	56	45	8	3152	3147	162	12	2380	2800
010.75.3550	3776	3322	174	3686	3414	56	45	8	3552	3547	162	12	2690	3200
010.75.4000	4226	3772	174	4136	3864	60	45	10	4002	3997	162	12	3020	3600
010.75.4500	4726	4272	174	4636	4364	60	45	10	4502	4497	162	12	3410	4000

Four Point Contact Ball Slewing Bearing (Internal Gear)

Features and Benefits:

An Outer Ring and Inner Ring/42CrMo or 50Mn

Inter Gear Type

Steel Balls/GrCr15 orGrCr15SiMn、Separators

NBR Seals

Tolerance and Clearance Available

Precision/P0、P2、P4、P5

Brand/LYNBC、OEM、ODM

Quality Exchangeable with RotheErde、SKF、INA、IMO、Kaydon、Silverthin Bearing

Designation	Boundary Dimension			Mounting Hole Size						Structure Size			Gear Data					Tangential Tooth Load		Basic load ratings	Mass (kg)
	D	d	H	D₁	D₂	n	Φ mm	n₁	D₃ mm	d₁	H₁	h	B mm	x	m mm	z	De mm	Z 10⁴N	T 10⁴N	Coa(10KN)
	mm			mm		n	Φ mm	n₁	D₃ mm	mm			B mm	x	m mm	z	De mm	Z 10⁴N	T 10⁴N	Coa(10KN)
013.30.500	602	398	80	566	434	20	18	4	501	498	70	10	60	+0.5	5	74	367	3.7	5.2	129	85
014.30.500	602	398	80	566	434	20	18	4	501	498	70	10	60	+0.5	6	62	368	4.5	6.2	129	85
013.30.560	662	458	80	626	494	20	18	4	561	558	70	10	60	+0.5	5	86	427	3.7	5.2	144	95
014.30.560	662	458	80	626	494	20	18	4	561	558	70	10	60	+0.5	6	72	428	4.5	6.2	144	95
013.30.630	732	528	80	696	564	24	18	4	631	628	70	10	60	+0.5	6	83	494	4.5	6.2	187	110
014.30.630	732	528	80	696	564	24	18	4	631	628	70	10	60	+0.5	8	62	491	6	8.3	187	110
013.30.710	812	608	80	776	644	24	18	4	711	708	70	10	60	+0.5	6	96	572	4.5	6.2	212	120
014.30.710	812	608	80	776	644	24	18	4	711	708	70	10	60	+0.5	8	72	571	6	8.3	212	120
013.40.800	922	678	100	878	722	30	22	6	801	798	90	10	80	+0.5	8	80	635	8	11.1	313	220
014.40.800	922	678	100	878	722	30	22	6	801	798	90	10	80	+0.5	10	64	634	10	14	313	220
013.40.900	1022	778	100	978	822	30	22	6	901	898	90	10	80	+0.5	8	93	739	8	11.1	355	240
014.40.900	1022	778	100	978	822	30	22	6	901	898	90	10	80	+0.5	10	74	734	10	14	355	240
013.40.1000	1122	878	100	1078	922	36	22	6	1001	998	90	10	80	+0.5	10	83	824	10	14	394	270
013.40.1000	1122	878	100	1078	922	36	22	6	1001	998	90	10	80	+0.5	12	69	821	12	16.7	394	270
013.40.1120	1242	998	100	1198	1042	36	22	6	1121	1118	90	10	80	+0.5	10	95	944	10	14	443	300
014.40.1120	1242	998	100	1198	1042	36	22	6	1121	1118	90	10	80	+0.5	12	79	941	12	16.7	443	300
013.45.1250	1390	1110	110	1337	1163	40	26	5	1252	1248	100	10	90	+0.5	12	88	1049	13.5	18.8	554	420
014.45.1250	1390	1110	110	1337	1163	40	26	5	1252	1248	100	10	90	+0.5	14	75	1042	15.8	21.9	554	420
013.45.1400	1540	1260	110	1487	1313	40	26	5	1402	1398	100	10	90	+0.5	12	100	1193	13.5	18.8	617	480
014.45.1400	1540	1260	110	1487	1313	40	26	5	1402	1398	100	10	90	+0.5	14	86	1196	15.8	21.9	617	480
013.45.1600	1740	1460	110	1687	1513	45	26	5	1602	1598	100	10	90	+0.5	14	100	1392	15.8	21.9	702	550
014.45.1600	1740	1460	110	1687	1513	45	26	5	1602	1598	100	10	90	+0.5	16	87	1382	18.1	25	702	550
013.45.1800	1940	1660	110	1887	1713	45	26	5	1802	1798	100	10	90	+0.5	14	113	1574	15.8	21.9	793	610
014.45.1800	1940	1660	110	1887	1713	45	26	5	1802	1798	100	10	90	+0.5	16	99	1574	18.1	25	793	610
013.60.2000	2178	1825	144	2110	1891	48	33	8	2002	1998	132	12	120	+0.5	16	109	1734	24.1	21.9	1210	1100
014.60.2000	2178	1825	144	2110	1891	48	33	8	2002	1998	132	12	120	+0.5	18	97	1735	27.1	25	1210	1100
013.60.2240	2418	2065	144	2350	2131	48	33	8	2242	2238	132	12	120	+0.5	16	125	1990	24.1	33.3	1350	1250
014.60.2240	2418	2065	144	2350	2131	48	33	8	2242	2238	132	12	120	+0.5	18	111	1987	27.1	37.5	1350	1250
013.60.2500	2678	2325	144	2610	2391	56	33	8	2502	2498	132	12	120	+0.5	18	125	2239	27.1	37.5	1500	1400
014.60.2500	2678	2325	144	2610	2391	56	33	8	2502	2498	132	12	120	+0.5	20	112	2228	30.1	41.8	1500	1400
013.60.2800	2978	2625	144	2910	2691	56	33	8	2802	2798	132	12	120	+0.5	18	141	2527	27.1	37.5	1680	1600
014.60.2800	2978	2625	144	2910	2691	56	33	8	2802	2798	132	12	120	+0.5	20	127	2528	30.1	41.8	1680	1600
013.75.3150	3376	2922	174	3286	3014	56	45	8	3152	3147	162	12	150	+0.5	20	142	2828	37.7	52.2	2380	2800
014.75.3150	3376	2922	174	3286	3014	56	45	8	3152	3147	162	12	150	+0.5	22	129	2825	41.5	57.4	2380	2800
013.75.3550	3776	3322	174	3686	3414	56	45	8	3552	3547	162	12	150	+0.5	20	162	3228	37.7	52.2	2690	3200
014.75.3550	3776	3322	174	3686	3414	56	45	8	3552	3547	162	12	150	+0.5	22	147	3221	41.5	57.4	2690	3200
013.75.4000	4226	3772	174	4136	3864	60	45	10	4002	3997	162	12	150	+0.5	22	167	3661	41.5	57.4	3020	3600
014.75.4000	4226	3772	174	4136	3864	60	45	10	4002	3997	162	12	150	+0.5	25	147	3660	47.1	65.2	3020	3600
013.75.4500	4726	4272	174	4636	4364	60	45	10	4502	4497	162	12	150	+0.5	22	190	4167	41.5	57.4	3410	4000
014.75.4500	4726	4272	174	4636	4364	60	45	10	4502	4497	162	12	150	+0.5	25	167	4160	47.1	65.2	3410	4000

Four Point Contact Ball Slewing Bearing (No Gear)

Features and Benefits:

An Outer Ring and Inner Ring/42CrMo or 50Mn

No Gear Type

Steel Balls/GrCr15 orGrCr15SiMn、Separators

NBR Seals

Tolerance and Clearance Available

Precision/P0、P2、P4、P5

Brand/LYNBC、OEM、ODM

Quality Exchangeable with RotheErde、SKF、INA、IMO、Kaydon、Silverthin Bearing.

Designation	Boundary Dimension			Mounting Hole Size				Structure Size					Gear Data					Tangential Tooth Load		Basic load ratings	Mass (kg)
	D	d	H	D₁	D₂	n	Φ mm	n₁	D₃	d₁	H₁	h	B mm	x	m mm	z	De mm	Z 10⁴N	T 10⁴N	Coa(10KN)
	mm			mm		n	Φ mm	n₁	mm				B mm	x	m mm	z	De mm	Z 10⁴N	T 10⁴N	Coa(10KN)
011.30.500	602	398	80	566	434	20	18	4	501	498	70	10	60	+0.5	5	123	629	3.7	5.2	129	85
012.30.500	602	398	80	566	434	20	18	4	501	498	70	10	60	+0.5	6	102	628.8	4.5	6.2	129	85
011.30.560	662	458	80	626	494	20	18	4	561	558	70	10	60	+0.5	5	135	689	3.7	5.2	144	95
012.30.560	662	458	80	626	494	20	18	4	561	558	70	10	60	+0.5	6	112	688.8	4.5	6.2	144	95
011.30.630	732	528	80	696	564	24	18	4	631	628	70	10	60	+0.5	6	126	772.8	4.5	6.2	187	110
012.30.630	732	528	80	696	564	24	18	4	631	628	70	10	60	+0.5	8	94	774.4	6	8.3	187	110
011.30.710	812	608	80	776	644	24	18	4	711	708	70	10	60	+0.5	6	139	850.8	4.5	6.2	212	120
012.30.710	812	608	80	776	644	24	18	4	711	708	70	10	60	+0.5	8	104	854.4	6	8.3	212	120
011.40.800	922	678	100	878	722	30	22	6	801	798	90	10	80	+0.5	8	118	966.4	8	11.1	313	220
012.40.800	922	678	100	878	722	30	22	6	801	798	90	10	80	+0.5	10	94	968	10	14	313	220
011.40.900	1022	778	100	978	822	30	22	6	901	898	90	10	80	+0.5	8	130	1062	8	11.1	355	240
012.40.900	1022	778	100	978	822	30	22	6	901	898	90	10	80	+0.5	10	104	1068	10	14	355	240
011.40.1000	1122	878	100	1078	922	36	22	6	1001	998	90	10	80	+0.5	10	116	1188	10	14	394	270
012.40.1000	1122	878	100	1078	922	36	22	6	1001	998	90	10	80	+0.5	12	96	1186	12	16.7	394	270
011.40.1120	1242	998	100	1198	1042	36	22	6	1121	1118	90	10	80	+0.5	10	127	1298	10	14	443	300
012.40.1120	1242	998	100	1198	1042	36	22	6	1121	1118	90	10	80	+0.5	12	106	1306	12	16.7	443	300
011.45.1250	1390	1110	110	1337	1163	40	26	5	1252	1248	100	10	90	+0.5	12	118	1450	13.5	18.8	554	420
012.45.1250	1390	1110	110	1337	1163	40	26	5	1252	1248	100	10	90	+0.5	14	101	1453	15.8	21.9	554	420
011.45.1400	1540	1260	110	1487	1313	40	26	5	1402	1398	100	10	90	+0.5	12	131	1606	13.5	18.8	617	480
012.45.1400	1540	1260	110	1487	1313	40	26	5	1402	1398	100	10	90	+0.5	14	112	1607	15.8	21.9	617	480
011.45.1600	1740	1460	110	1687	1513	45	26	5	1602	1598	100	10	90	+0.5	14	127	1817	15.8	21.9	702	550
012.45.1600	1740	1460	110	1687	1513	45	26	5	1602	1598	100	10	90	+0.5	16	111	1821	18.1	25	702	550
011.45.1800	1940	1660	110	1887	1713	45	26	5	1802	1798	100	10	90	+0.5	14	141	2013	15.8	21.9	793	610
012.45.1800	1940	1660	110	1887	1713	45	26	5	1802	1798	100	10	90	+0.5	16	123	2013	18.1	25	793	610
011.60.2000	2178	1825	144	2110	1891	48	33	8	2002	1998	132	12	120	+0.5	16	139	2269	24.1	33.3	1210	1100
012.60.2000	2178	1825	144	2110	1891	48	33	8	2002	1998	132	12	120	+0.5	18	123	2264	27.1	37.5	1210	1100
011.60.2240	2418	2065	144	2350	2131	48	33	8	2242	2238	132	12	120	+0.5	16	153	2493	24.1	33.3	1350	1250
012.60.2240	2418	2065	144	2350	2131	48	33	8	2242	2238	132	12	120	+0.5	18	136	2498	27.1	37.5	1350	1250
011.60.2500	2678	2325	144	2610	2391	56	33	8	2502	2498	132	12	120	+0.5	18	151	2768	27.1	37.5	1500	1400
012.60.2500	2678	2325	144	2610	2391	56	33	8	2502	2498	132	12	120	+0.5	20	136	2776	30.1	41.8	1500	1400
011.60.2800	2978	2625	144	2910	2691	56	33	8	2802	2798	132	12	120	+0.5	18	168	3074	27.1	37.5	1680	1600
012.60.2800	2978	2625	144	2910	2691	56	33	8	2802	2798	132	12	120	+0.5	20	151	3076	30.1	41.8	1680	1600
011.75.3150	3376	2922	174	3286	3014	56	45	8	3152	3147	162	12	150	+0.5	20	171	3476	37.7	52.2	2380	2800
012.75.3150	3376	2922	174	3286	3014	56	45	8	3152	3147	162	12	150	+0.5	22	155	3472	41.5	57.4	2380	2800
011.75.3550	3776	3322	174	3686	3414	56	45	8	3552	3547	162	12	150	+0.5	20	191	3876	37.7	52.2	2690	3200
012.75.3550	3776	3322	174	3686	3414	56	45	8	3552	3547	162	12	150	+0.5	22	174	3890	41.5	57.4	2690	3200
011.75.4000	4226	3772	174	4136	3864	60	45	10	4002	3997	162	12	150	+0.5	22	194	4330	41.5	57.4	3020	3600
012.75.4000	4226	3772	174	4136	3864	60	45	10	4002	3997	162	12	150	+0.5	25	171	4345	47.1	65.2	3020	3600
011.75.4500	4726	4272	174	4636	4364	60	45	10	4502	4497	162	12	150	+0.5	22	217	4836	41.5	57.4	3410	4000
012.75.4500	4726	4272	174	4636	4364	60	45	10	4502	4497	162	12	150	+0.5	25	191	4845	47.1	65.2	3410	4000

Four Point Contact Ball Slewing Bearing Key Features

Four-Point Contact: The special raceway design enables the balls to contact both the inner and outer ring at four points, allowing the bearing to support high loads in all directions.

Compact Design: Single-row construction reduces weight and space requirements while maintaining high load capacity.

High Load Capacity: Can handle axial, radial, and tilting moment loads efficiently.

Low Friction & Smooth Rotation: Designed for stable movement with minimal resistance.

Easy Maintenance: Simple lubrication points and easy-to-install structure.

Structure & Components

Outer Ring: Stationary or rotating component with an integrated raceway.

Inner Ring: Supports the load and connects to the rotating part of the machine.

Rolling Elements (Balls): Typically made of high-quality steel for durability and smooth movement.

Cage or Spacer: Separates the balls and ensures even load distribution.

Seals & Lubrication Ports: Protect against contaminants and enable easy maintenance.

Applications

Four-point contact ball slewing bearings are widely used in various industries due to their ability to handle complex loads. Common applications include:

Cranes (tower cranes, mobile cranes, port cranes)

Excavators & Construction Equipment

Wind Turbines

Robotic Arms & Turntables

Medical Equipment (CT Scanners, MRI Machines)

Defense & Radar Systems

Advantages

Handles multiple load types (axial, radial, moment)

Compact and lightweight compared to other slewing bearings

Lower friction and longer service life with proper lubrication

Easy to install and replace
